xTool F2 Ultra UV 5W Laser Engraver
Professional UV Laser Engraving for Glass, Acrylic & More
The xTool F2 Ultra UV is a professional 5W UV laser engraving machine designed for high-speed, precise engraving and cutting across a wide range of materials. Its 355 nm UV laser delivers fine, detailed results and is especially well suited for glass, crystal, acrylic, plastics, ceramics and other materials that can be challenging for conventional laser systems.
5W UV Laser Technology
The 355 nm UV laser provides precise, high-quality processing for a wide variety of materials, including:
- Glass
- Crystal
- Acrylic
- Wood
- Metal
- Leather
- Plastic
- Rubber
- Silicone
- Ceramic
- And more
The F2 Ultra UV can also cut compatible materials such as certain plastics, fabric, leather, acrylic, paper and wood.
Exceptional Glass Engraving
One of the major advantages of UV laser technology is its ability to produce detailed results on glass and crystal. The F2 Ultra UV is designed for smooth, uniform engraving, making it particularly valuable for premium personalization, awards, gifts, drinkware and decorative products.
High-Speed Production
With processing speeds of up to 15,000 mm/s, the F2 Ultra UV is built for efficient production and batch personalization. Its high-speed workflow makes it suitable for businesses producing custom products at scale.
Large & Flexible Working Area
The machine provides:
- Inner engraving: 70 × 70 mm
- Surface engraving: 200 × 200 mm
- Surface engraving with conveyor: up to 200 × 500 mm
This combination provides flexibility for both small detailed projects and larger production workflows.
48MP Dual-Camera Positioning
The integrated 48MP dual-camera system provides smart visual positioning, autofocus and a real-time preview of the work area. Camera positioning accuracy is specified at approximately 0.2 mm, helping simplify alignment and improve consistency during batch production.
3D Inner Engraving
The F2 Ultra UV supports inner engraving, allowing you to create detailed designs inside compatible transparent materials such as glass and crystal. xTool also highlights one-click 3D model generation from images or text to simplify this type of project.
Built for Professional Personalization
Create:
- Personalized glassware
- Crystal awards
- Acrylic products
- Jewelry
- Promotional products
- Custom gifts
- Decorative items
- Ceramic products
- Personalized signage
- Premium corporate gifts
xTool Studio
The F2 Ultra UV works with xTool Studio on Windows and macOS. It supports USB, Wi-Fi and IP connectivity, allowing the machine to integrate into different production environments.
Smart Production Features
The machine comes pre-assembled and includes:
- Autofocus
- Smart Camera Preview
- Dual 48MP cameras
- LiDAR ranging system
- Camera positioning
- High-speed light live preview
- Conveyor compatibility
These features are designed to make positioning, setup and repeat production easier.
Technical Specifications
| Specification | Details |
|---|---|
| Laser Type | 5W UV Laser |
| Laser Wavelength | 355 nm |
| Inner Engraving Area | 70 × 70 mm |
| Surface Engraving Area | 200 × 200 mm |
| Surface Area with Conveyor | 200 × 500 mm |
| Maximum Speed | 15,000 mm/s |
| Maximum Processing Height | 150 mm |
| Maximum Rotary Diameter | 150 mm |
| Built-in Cameras | 48MP Dual Cameras |
| Positioning Accuracy | 0.2 mm |
| Software | xTool Studio |
| Operating System | Windows / macOS |
| Connection | USB / Wi-Fi / IP |
| Safety Certification | Class 4 Laser Safety |
| Machine Dimensions | 294 × 429 × 520 mm |
| Voltage | 110V / 220V |
These specifications are based on xTool's current product and support documentation.
Important Safety Information
The xTool F2 Ultra UV is classified as a Class 4 laser system. Appropriate laser safety procedures, installation requirements and protective measures must be followed during operation. Always follow the manufacturer's safety instructions and applicable regulations.
